Walter Tools
G5011-1212L-2.5T12GD26
Shank tool – Radial grooving
EAN-code: 4063467724472
Screw clamping
Checking availability
You need to log in before purchasing.
Request credentials here.
Ask about this product
Ask about this product
Technical details
Description
Symbol
Value
Shank width
b
12 mm
Maximum cutting depth
Tmax
12 mm
Indexable insert width
s
2.5
Shank height
h = h1
12 mm
Hand
HAND
L
Shank height
h4
4 mm
Overall length
l1
119,5 mm
Maximum projection length
l4
29,5 mm
Tool designation
Designation
G5011-1212L-2.5T12GD26
Possible indexable inserts
Type
GD26-2.5 ..
Body width
s1
2,1 mm
Functional width
f1
10,9 mm
Weight
WT
0,13 kg
