Walter Tools WL25-VCGT0708NFS-3 WDN10
PCD – Indexable inserts copy turning system

EAN-code: 4063467658111

P

M

K

N

S

H

O

Checking availability

You need to log in before purchasing. Request credentials here.

Ask about this product

Description Symbol Value

Depth of cut

a_p

0.1–3.0 mm

Feed rate

f

0.03–0.38 mm

Delta

δ

10 °

Diameter of inscribed circle

d

12,7 mm

Cutting edge length

l

25 mm

Cutting edge effective length

l_e

4,12 mm

Designation

WL25-VCGT0708NFS-3 WDN10

Radius

R

0,8 mm

Insert thickness

s

4,76 mm
