Walter Tools
M6420-100-B32-07-02
High-Feed-Fräser
NEW 2026
EAN-code: 4063467930187
4 cutting edges per indexable insert
P
M
K
N
S
H
O
VAT 0%
960,00 €
Checking availability
You need to log in before purchasing.
Request credentials here.
Ask about this product
Ask about this product
Technical details
Description
Symbol
Value
Cutting edge length
Lc
2 mm
Number of indexable inserts
No. of inserts
7
Maximum radial depth of cut
ar
8 mm
Cutting diameter
Dc
89,6 mm
Connection diameter
d1
32
Maximum cutting diameter
Da
100 mm
Lead angle
KAPR
20 °
Functional length
l4
60 mm
Tool designation
Designation
M6420-100-B32-07-02
Maximum ramping angle
RMPX
0,5 °
Maximum speed
RPMX
9200 r/min
Possible indexable inserts
Type
ENMX110616R
Weight
WT
1,53 kg
Number of teeth
Z
7
